ZH-A Computerized Quilting and Embroidery All-in-One Machine
Machine Performance:
Integrated quilting and embroidery in one step.
Y-direction driven by roller transmission.
Tension motors for feeding and discharging ensure fabric remains smooth.
X/Y axes controlled by Panasonic servo motors for precise embroidery.
Automatic stop in case of thread breakage.
Automatic backtracking and repair stitching.
Optional quilting and embroidery with any sewing head.
Connected quilting with independent patterns and jump-stitch function.
Compatible with Tajima, PAD, ZSK, and SWF embroidery file formats.
Unique mechanical structure reduces inherent vibration, enabling better control over vibrations and lower noise levels.
Japanese-made rotary hooks with high-quality materials and large capacity, reducing the frequency of bobbin changes.
Machine Functions:
Suitable for quilting products: apparel, sleeping bags, summer quilts, mattresses, various cushions, etc.
This equipment is an innovative model combining quilting and embroidery technologies, delivering uniform, smooth, and elegant stitches.
Patterns range from simple to complex.
Main Parameters:
Main Shaft Motor: Servo motor
X/Y Axis Motors: Servo motors
Stitch Length: 0.15–12.7 mm
Rotary Hook: Model 20-R
Sewing Head: 3-color interchangeable head
Voltage: 3-phase 380V 50Hz
